Incinerator Furnace

 Product Introduction

Jiangsu Jufeng Thermal Co., Ltd.'s Solid Waste/Hazardous Waste Incineration System is a high-efficiency disposal solution developed by leveraging the scientific research advantages of the Thermal Energy and Power Engineering Department of a renowned university. It is specifically designed to address the complex composition and fluctuating calorific value of industrial solid waste and hazardous waste. The system strictly adheres to the "3T+1E" incineration principle (Temperature, Time, Turbulence, Excess Air) to ensure harmless treatment, volume reduction, and resource recovery of hazardous waste.


Get In Touch Download PDF
PREV：Smelting Furnace NEXT：Biomass Gasifier

Product Description

Core Technology & Processes

Targeting solid and hazardous waste of different natures, we adopt differentiated process packages. Our incinerator models include:

-Single-Chamber Furnace: Suitable for batch processing and waste with relatively stable composition.
- Walking Hearth Furnace: Ideal for materials requiring gradual heating.
- Chain Grate Stoker: Suitable for granular waste with good uniformity.
- Rotary Kiln: Highly adaptable, suitable for complex, diverse, and challenging hazardous waste streams.

Applications

This system is widely used in: industrial hazardous waste treatment centers, chemical industry parks, medical waste treatment facilities, electronic waste processing plants, and organic sludge treatment facilities.

Features of the Direct-Fired Incinerator
  • High-Efficiency Sterilization & Clean Emissions
    -High-temperature sterilization process achieves smoke-free and odor-free operation, eliminating secondary pollution.
    -Two-stage high-temperature incineration design with precise temperature control between 850°C and 1100°C, and a flue gas residence time of over 2 seconds, ensuring complete decomposition of organic compounds.
  • Advanced Flue Gas Cleaning System
    - Cyclone Dust Removal: Primary removal of particulate matter from flue gas.
    - Quench Tower: Rapidly cools flue gas to below 200°C, effectively inhibiting dioxin re-synthesis.
    - Dry Absorption Unit: Removes acid gases and dioxin components from the flue gas.
    - Baghouse Filter: Final removal of fine dust particles; clean flue gas is discharged into the atmosphere via an induced draft fan.
  • Innovative Furnace Design
    - Overcomes limitations of traditional fixed grates, such as uneven temperature distribution, surface carbonization of waste, incomplete combustion, and high energy consumption.
    - Customizes furnace design based on the physical and chemical properties of the materials. Utilizes differentiated lining materials to ensure rapid combustion, prevent furnace lining corrosion, and significantly extend equipment lifespan.
  • Energy Saving & Multi-Function Incineration
    - Patented air injection and guidance system achieves perfect combustion with a lower excess air ratio, reducing heat loss inside the furnace.
    - High-pressure air fluidized bed combustion technology + Double grate suspension combustion design significantly improves combustion efficiency.
    - Equipped with waste liquid and waste gas burners, enabling multi-functional co-incineration of solid, liquid, and gaseous waste.
  • Intelligent Operation
    - Comprehensive flue gas treatment system ensures zero secondary pollution throughout the process.
    - Optional automatic waste feeding and ash discharge systems enable continuous and automated operation.
